Interface
• 48 10/100Base-TX Ethernet ports
• 2 Combo 10/100/1000Base-T/SFP Gigabit Uplinks
• 2 Gigabit copper ports
Performance/Resilience
• Switch fabric: 17.6 Gbps
Security
• ACL based on MAC address or IP address (ICMP/IGMP/TCP/UDP)
• 802.1X RADIUS authentication support
• IP-MAC-port binding
• DHCP Snooping1
• DHCP Server Screening1
• D-Link Safeguard Engine™
VLAN
• 802.1Q VLAN Tagging
• Max. 256 static VLAN groups
• Max. 4094 VIDs
• Management VLAN
• Asymmetric VLAN
• Auto Voice VLAN
Quality of Service (QoS)
• 802.1p Priority Queues, 4 queues per port
• Port based bandwidth control (granularity down to 64 kbps)
Traffic Management
• 802.3x Flow Control
• Port mirroring
• Broadcast/Multicast/Unicast Storm Control
• 802.3ad Link Aggregation (up to 8 groups, 8 ports per group)
• IGMP Snooping (v1/v2)
Configuration/Management
• Web-based GUI
• SmartConsole utility
• Command Line Interface (CLI) through Telnet
• Supports D-View SNMP network management
1available in a future firmware release
