| Specifications | |||
| Scanner Type | A4 sheet-fed, one-pass duplex colour scanner | ||
| Sensor | Contact Image Scanner (CIS) | ||
| Light Source | RGB LED | ||
| Optical Resolution*1 | 600 x 600 dpi | ||
| Output Resolution | 75 – 1,200 dpi (in 1 dpi increments) | ||
| Min. Document Size | 52.0 x 50.8mm (2.05" x 2.00") | ||
| Max. Document Size | 215.9 x 3048mm (8.5" x 120") | ||
| Supported Paper Weight | 40 – 210g/m2 | ||
| ADF Capacity | 80 sheets (80g/m2) | ||
| Scanning Speed*2 | Colour (24-bit) | Grey (8-bit) | Mono (1-bit) |
| Resolution | Simplex / Duplex | Simplex / Duplex | Simplex / Duplex |
200dpi |
65ppm / 130ipm | 65ppm / 130ipm | 65ppm / 130ipm |
300dpi |
65ppm / 130ipm | 65ppm / 130ipm | 65ppm / 130ipm |
400dpi |
9ppm / 18ipm | 40ppm / 80ipm | 40ppm / 80ipm |
600dpi |
7ppm / 14ipm | 30ppm / 60ipm | 30ppm / 60ipm |
| Daily Scan Volume | 6,000 pages / day | ||
| Multi-Feed Detection | Ultrasonic Sensor | ||
| Driver | Epson Scan TWAIN Driver, ISIS Driver | ||
| Interface | USB 2.0 Hi-Speed, Ethernet (with optional Network Interface Unit) | ||
| Supported Platforms | |||
| Epson Scan Twain Driver | Windows XP / Vista / 7 / 8 / 8.1 / Server 2003 / Server 2008 / Server 2012 | ||
| ISIS Driver | Windows XP / Vista / 7 / 8 / 8.1 | ||
| Electrical Specifications | |||
| Rated Voltage | AC100 – 240V | ||
| Rated Frequency | 50 – 60Hz | ||
| Power Consumption | |||
| Operating | Approx. 42W | ||
| Ready | Approx. 8W | ||
| Sleep | Approx. 1.6W | ||
| Off | < 0.4W | ||
| Environmental Conditions | |||
| Temperature | |||
Operating |
5 – 35˚C | ||
Storage |
-25 – 60˚C | ||
| Humidity | |||
Operating |
10 – 80% (No condensation) | ||
Storage |
10 – 85% (No condensation) | ||
| Driver and Bundled Software | |||
| Epson Scan v5.3 | |||
| ISIS Driver | |||
| Document Capture Pro (Windows only) | |||
| Options / Consumables | Order Code | Durability | |
| Network Interface Unit | B12B808461 | - | |
| Roller Assembly Kit | B12B813581 | 200,000 scans | |
| Carrier Sheet | B12B813431 | 3,000 scans | |
