• CPU (MAX SUPPORT)

i9

• SOCKET

1700

• CHIPSET

Intel® Z690 Chipset

• DDR4 MEMORY

5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz

• MEMORY CHANNEL

Dual

• DIMM SLOTS

4

• MAX MEMORY (GB)

128

• PCI-E X16

3

• PCI-E X1

 1

• SATAIII

6

• M.2 SLOT

4

• RAID

0/1/5/10

• TPM (HEADER)

 1

• LAN

1x Intel® I225-V 2.5Gbps LAN

• USB 3.2 PORTS (FRONT)

1(Gen 2, Type C), 4(Gen 1, Type A)

• USB 3.2 PORTS (REAR)

1(Gen 2x2, Type C), 1(Gen 2, Type A), 2(Gen 1, Type A)

• USB 2.0 PORTS (FRONT)

4

• USB 2.0 PORTS (REAR)

4

• DIMENSION

• AUDIO PORTS (REAR)

Realtek® ALC897 Codec

• DISPLAYPORT

 1

• HDMI

1

• DIRECTX

12

• FORM FACTOR

ATX

• CROSSFIRE

Y

• OPERATING SYSTEM

Support for Windows® 11 64-bit, Windows® 10 64-bit
