Camera |
|
|
Image Sensor: |
2MP CMOS Image Sensor |
|
Signal System: |
PAL/NTSC |
|
Effective Pixels: |
1920(H)*1080(V) |
|
Min. Illumination: |
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR |
|
Shutter Time: |
1/25(1/30) s to 1/50,000 s |
|
Lens: |
2.8mm, 3.6mm, 6mm optional |
|
Lens Mount: |
M12 |
|
Adjustment Range: |
Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
|
Day& Night: |
IR cut filter with auto switch |
|
Video Frame Rate: |
1080p@25fps/1080p@30fps |
|
HD Video Output: |
1 Analog HD output |
|
Synchronization: |
Internal Synchronization |
|
S/N Ratio: |
More than 62 dB |
|
General |
|
|
Operating Conditions: |
-20 °C - 45 °C (-4 °F - 113 °F) |
|
Power Supply: |
12 VDC±15% |
|
Power Consumption: |
Max. 4W |
|
Weather Proof: |
IP66 |
|
IR Range: |
Up to 40m |
|
Dimension: |
Φ110 × 93.2 mm(Φ4.33” × 3.67”) |
|
Weight: |
350 g |
